Infineon FP15R06YE3-B4 600V IGBT Module
Regular price
Rs.8,500.00
Sale price
Rs.9,500.00
FP15R06YE3-B4
The FP15R06YE3-B4 is an Infineon (EUPEC) 600 V IGBT power module designed for medium-power applications in industrial power electronics. It provides stable switching performance, controlled thermal behaviour, and a compact EASY2 package suitable for inverters, motor drives, UPS equipment, and power conversion systems used in commercial and industrial environments.
This module supports low conduction and switching losses, contributing to consistent electrical performance under varying load conditions. Its defined gate-emitter limits, predictable switching characteristics, and thermal ratings assist in developing reliable gate-drive and protection circuits. These features make the FP15R06YE3-B4 appropriate for installations where temperature stability, long operating cycles, and dependable electrical characteristics are required.
The EASY2 mechanical format, standard pin-out and screw-mount design simplify integration into existing and new circuit layouts. The module’s electrical ratings, mounting dimensions, and operational parameters should be reviewed in the official datasheet to ensure proper selection for inverters, drives, and other power control systems.
Key Specs
| Parameter | Value |
|---|---|
| Manufacturer | Infineon (EUPEC) |
| Part Number | FP15R06YE3-B4 |
| Type | IGBT Power Module (EASY2 Package) |
| Collector–Emitter Voltage (VCE) | 600 V |
| Continuous Collector Current (IC) | ~22 A (25 °C) |
| VCE(sat) | ~1.55 V (typical) |
| Maximum Operating Temperature | +150 °C |
| Gate–Emitter Voltage | ±20 V |
| Power Dissipation | ~71.5 W |
| Package Dimensions | Approx. 55.9 × 45.6 × 12 mm |
