SKD 33/16 Three-Phase Diode Bridge Module
The SKD 33/16 is a three-phase diode bridge module designed for industrial and commercial power electronics applications. Rated for 1600 V reverse voltage and 33 A forward current at 85 °C, this module ensures reliable performance in high-power systems. Its SEMIPACK housing provides efficient thermal management and mechanical stability, allowing safe integration into motor drives, inverters, and power converters.
Built for durability and efficiency, the SKD 33/16 supports a wide operating temperature range of −40 °C to +125 °C and features high surge current capability, enabling continuous operation under fluctuating or high-load conditions. The module’s insulated ceramic base and robust soldering ensure long-term reliability and reduce maintenance requirements, making it suitable for continuous industrial usage.
Ideal for applications such as AC motor drives, welding equipment, temperature control systems, and power conversion units, the SKD 33/16 combines compact SEMIPACK form factor with excellent electrical isolation and heat dissipation. Its standard screw-mount design allows easy installation in confined or complex system layouts.
Key Specs:
| Specification | Value |
|---|---|
| Module Type | Three-Phase Diode Bridge Module |
| Voltage Rating (V_RRM/V_DRM) | 1600 V |
| Average Forward Current (I_TAV) | 33 A at 85 °C |
| Surge On-State Current (I_TSM) | 500 A |
| Thermal Resistance (R_thJC) | 1.2 °C/W |
| Junction Temperature (T_jmax) | 125 °C |
| Package Type | SEMIPACK |
| Housing Material | Aluminum Oxide Ceramic |
| Mounting Type | Screw Mount |
| Weight | 110 g |
