SCE200DA160 Thyristor Module
The SCE200DA160 is a high-performance thyristor power module designed for demanding industrial and commercial power electronics. With a 200A RMS output current and 1600V blocking voltage, it delivers efficient power handling and secure switching, making it ideal for applications such as inverters, motor drives, and industrial power supplies.
Engineered for durability, the module features a robust chassis-mount design and operates across a wide temperature range from –40 °C to +125 °C, ensuring long-term stability even in harsh environments. Its low forward voltage drop of approximately 1.34 V contributes to high efficiency while minimizing energy losses.
With a surge current capability of up to 6,500 A and precise gate control (100 mA trigger current), the SCE200DA160 provides both power resilience and safe operation. This makes it a reliable choice for industries requiring efficiency, ruggedness, and consistent performance in heavy-duty power management systems.
Key Specifications
| Specification | Value |
|---|---|
| Output Current (It(AV)) | 200 A RMS |
| Voltage Rating (Reverse, Vr) | 1600 V |
| Gate Trigger Current (Igt) | 100 mA |
| Gate Trigger Voltage (Vgt) | 3 V |
| Forward Voltage Drop (Vf) | ~1.34 V |
| Surge Current (Itsm, 60 Hz) | 6,500 A |
| I²t (A²s) | 180,000 A²s |
| Thermal Resistance (Rth j-c) | 0.155 °C/W |
| Operating Temperature (Tj) | –40 °C to +125 °C |
| Package Type & Mounting | Chassis-mount, Package 29B |
| Configuration | Phase-leg (Thyristor + Diode) |
