Fuji 6MBI15LS-060-01
The Fuji 6MBI15LS-060-01 is a six-pack IGBT module designed for use in power electronics systems. It provides a collector-emitter voltage rating of 600 V and a continuous collector current of 15 A per transistor element, making it suitable for inverters, motor drives, UPS systems, and welding equipment.
This module offers low saturation voltage and fast switching behavior, which helps reduce power loss and improves efficiency. Its M619 package with PCB mounting is compact and easy to integrate, while the RoHS-compatible design supports compliance with industrial standards. The construction ensures stable operation even under extended duty cycles.
The 6MBI15LS-060-01 is widely used in three-phase inverter circuits, AC/DC servo drives, and power backup equipment. With its six integrated IGBT elements, it simplifies circuit design compared to using discrete devices. For complete electrical ratings, mechanical dimensions, and detailed specifications, please refer to the official Fuji Electric datasheet linked below.
Key Specs
| Specification | Value |
|---|---|
| Part number | 6MBI15LS-060-01 |
| Manufacturer | Fuji Electric |
| Device type | IGBT module (6-pack) |
| Collector-Emitter voltage (V_CES) | 600 V |
| Continuous collector current (per IGBT) | 15 A |
| Case / Package | M619 (PCB mount) |
| Typical applications | Motor drives, inverters, AC/DC servo drives, UPS, welding machines |
| Dimensions (W×H×D) | approx. 8.0 cm × 5.5 cm × 1.2 cm |
| Weight | ≈ 0.060 kg |
For more detailed information, please refer to the Fuji Electric datasheet.
