270uF 550V Electrolytic Capacitor
Regular price
Rs.450.00
Sale price
Rs.550.00
270 uF 550V Electrolytic Capacitor
The 270 µF 550 V snap-in aluminum electrolytic capacitor is designed for use in high-voltage power electronics where stable capacitance and long operating life are required. It is commonly applied in DC link circuits, UPS systems, industrial inverters, motor drives, and high-power rectifiers. With a rated voltage of 550 V DC and a capacitance of 270 µF, this capacitor supports effective energy storage and ripple smoothing in industrial and commercial power supply designs.
This capacitor provides a rated lifetime of up to 15 000 hours at 85 °C, making it suitable for continuous operation in demanding environments. The device supports a high ripple current of approximately 2.66 A and features low ESR, which helps reduce internal heat generation and supports stable electrical performance. A capacitance tolerance of ±20 % allows for predictable behavior in regulated and unregulated power circuits.
Mechanically, the capacitor uses a snap-in radial package, enabling secure PCB mounting in high-vibration or high-current applications. It operates over a temperature range of −40 °C to +85 °C and complies with RoHS requirements. This component is part of the KEMET ALC70 series, which is widely used in industrial power electronics.
Key Specs
| Parameter | Specification |
|---|---|
| Capacitance | 270 µF |
| Rated Voltage | 550 V DC |
| Capacitance Tolerance | ±20 % |
| Ripple Current | ~2.66 A |
| Equivalent Series Resistance (ESR) | ~1.29 Ω |
| Rated Lifetime | 15 000 hours @ 85 °C |
| Operating Temperature Range | −40 °C to +85 °C |
| Package Type | Snap-in radial aluminum electrolytic |
| Lead Spacing | 10 mm |
| Case Dimensions | ~35 mm diameter × ~50 mm height |
| Polarity | Polarized |
| Compliance | RoHS |
| Manufacturer / Series | KEMET ALC70 series |
