Renesas RN75H65 650V 75A IGBT TO-247A
Regular price
Rs.300.00
Sale price
Rs.315.00
RN75H65 – 650 V / 75 A IGBT
The RN75H65 is an Insulated Gate Bipolar Transistor (IGBT) from Renesas, designed for high-efficiency power switching applications. Using advanced 8th-generation trench-gate, thin-wafer (G8H) technology, it features a low typical collector-emitter saturation voltage of 1.5 V at 75 A. The device includes a fast-recovery diode within its TO‑247A package, reducing circuit complexity and supporting reliable operation in power electronics systems.
This IGBT operates at a maximum junction temperature of 175 °C, suitable for UPS systems, welding equipment, photovoltaic inverters, and power converters. Its high-speed switching capabilities and thermal performance make it suitable for demanding industrial and commercial applications.
The RN75H65 provides low conduction losses, stable short-pulse handling up to 300 A, and optimized switching energy. Its combination of performance, efficiency, and durability allows integration into various power electronics designs while maintaining consistent operation under high-current and high-voltage conditions.
Key Specs
| Parameter | Value |
|---|---|
| Part Number | RBN75H65T1FPQ-A0 (RN75H65) |
| Collector–Emitter Voltage (VCES) | 650 V |
| Continuous Collector Current (IC) | 75 A @ 100 °C |
| Peak Collector Current | 300 A (short pulse) |
| Saturation Voltage (VCE(sat)) | ~1.5 V typ. |
| Built‑in Diode | Fast-recovery diode |
| Maximum Junction Temperature (Tj) | 175 °C |
| Package | TO‑247A |
| Thermal Resistance (J‑to‑C) | 0.48 °C/W (IGBT), 0.73 °C/W (Diode) |
| Switching Energy (Eon / Eoff) | ~1.6 mJ / ~1.0 mJ @ 400 V, 75 A |
| Diode Reverse Recovery Time (trr) | ~72 ns |
For detailed technical information, refer to the Renesas RN75H65 datasheet.
