Minco KF136 Terminal Block 65A 1000V PCB Connector

Minco KF136 PCB Terminal Block – 65A 1000V, 2–24 Pin, -40°C to +105°C, RoHS Compliant

Minco KF136 PCB Terminal Block is a high-current, high-voltage terminal block designed for reliable wire-to-board connections in power-intensive and industrial systems. Supporting up to 65A current and 1000V voltage, this robust connector ensures safe and stable performance across a wide range of demanding applications. Its PCB mount, direct-insert design simplifies assembly and enhances durability in large-scale projects.

Built with flame-retardant PA66 housing and brass metal parts, the KF136 operates efficiently in harsh conditions from -40°C to +105°C. It supports wire sizes from 20 to 6 AWG, and offers multiple pin options from 2P to 24P for compatibility with diverse system layouts. Fully RoHS compliant, it meets modern quality and environmental standards. This terminal block is widely used in automation systems, power distribution panels, industrial control cabinets, telecom infrastructure, and automotive and medical electronics.

Trusted by engineers, manufacturers, and procurement professionals, the Minco KF136 offers strong electrical performance, quick installation, and long-term reliability for high-load B2B applications.

Key Specs Brand: Minco Model: KF136 Current Rating: 65A Voltage Rating: 1000V Pin Options: 2P to 24P Wire Range: 20–6 AWG Temperature Range: -40°C to +105°C Housing Material: Flame-Retardant PA66 Contact Material: Brass Mounting: Direct Insert, PCB Compliance: RoHS Applications: Automation, Power Distribution, Industrial Control, Telecom, Automotive, Medical Electronics.
