DSEI60-06A IXYS 600V 60A Diode TO‑247

DSEI60-06A 600 V 60 A Fast Recovery Diode – TO‑247 Package by IXYS

The DSEI60-06A is a single-diode, fast recovery device designed using epitaxial FRED (Fast Recovery Epitaxial Diode) technology. It is rated for 600 V repetitive peak reverse voltage and supports an average forward current of 60 A. With a robust TO‑247AD package, the diode offers high surge current capability (up to 550 A), low forward voltage drop (≤ 1.8 V at 70 A), and ultra-fast reverse recovery times of 35–50 ns, making it suitable for high-speed switching circuits.

This diode is optimized for use in power electronics environments such as SMPS (switched-mode power supplies), motor control units, HVAC drives, and general-purpose power converters. Its thermal resistance and power dissipation of up to 166 W ensure reliable operation in demanding thermal conditions. The DSEI60-06A also supports junction temperatures from −55 °C to +150 °C and is avalanche energy tested, making it ideal for circuits where rugged performance and efficient switching are required.

Key Specs Voltage Rating: 600 V (V_RRM) Current Rating: 60 A Continuous Surge Current: 550 A typical peak (non-repetitive) Forward Voltage: ≤ 1.8 V @ 70 A Recovery Time (t_rr): 35 ns (typical), 50 ns (maximum) Power Dissipation: 166 W (at case temperature) Operating Temp Range: −55 °C to +150 °C Package: TO‑247AD (through-hole) Technology: Fast Recovery Epitaxial Diode (FRED) Applications: SMPS, motor control, HVAC, power management systems
