47uF 250V Radial Electrolytic Capacitor

47uF 250V Electrolytic Capacitor

The 47uF 250V capacitor is a high-voltage aluminum electrolytic radial capacitor. It offers stable energy storage and effective voltage filtering for power supply circuits, industrial equipment, and renewable energy systems. Rated for 250V and 47 microfarads, this capacitor helps suppress voltage fluctuations and protects downstream components in high-voltage environments.

This radial capacitor features low equivalent series resistance (ESR) and high ripple current capability. It supports reliable operation across fluctuating loads and minimizes heat generation in high-frequency circuits. Typical dimensions are around 12.5mm diameter × 25mm height with 5mm lead spacing, fitting many PCB layouts.

Operating temperature ranges from –40 °C to +105 °C with a tolerance of ±20%. The device offers a service life of 1000 to 5000 hours depending on the series (e.g. Nichicon UVZ, Rubycon 250PX). It is compliant with RoHS standards, ensuring environmental and industrial quality.

Key Specs Capacitance: 47uF Voltage Rating: 250V DC Type: Radial Aluminum Electrolytic Capacitor Tolerance: ±20% Operating Temperature: –40 °C to +105 °C Lifetime: 1000–5000 hours @ 105 °C ESR: Low Dimensions: ~12.5mm diameter × 25mm height; lead spacing ≈5mm Ripple Current: ~210–490 mA depending on series Applications: Power Supply Filtering, DC Link, Signal Coupling, Industrial Power Electronics, Solar Inverters, Motor Drives Compliance: RoHS Compliant
