PS21963-4A Intelligent Power Module
The PS21963-4A is an Intelligent Power Module (IPM) from Mitsubishi Electric, designed for reliable power conversion in industrial applications. This module integrates a 600V, 10A IGBT inverter bridge, suitable for three-phase DC-to-AC power conversion systems. Its design ensures low power loss and consistent performance, while the integrated protection features support stable operation under varying conditions.
The PS21963-4A is compatible with a range of applications in power electronics. Its 25-pin DIP package allows straightforward integration into systems such as motor drives for appliances, HVAC equipment, and industrial automation. The module supports a high voltage isolation of 1500VDC and an operating temperature range from -40°C to +125°C, enabling reliable operation in different environments.
Using the PS21963-4A simplifies system design and enhances reliability. Its integrated drive and protection circuits reduce the need for additional components, supporting efficient and stable power control for motor systems, inverters, and other power conversion applications.
Key Specifications
| Feature | Specification |
|---|---|
| Module Type | Intelligent Power Module |
| IGBT Rating | 600V / 10A |
| Package Type | 25-Pin DIP |
| Isolation Voltage | 1500VDC |
| Operating Temperature | -40°C to +125°C |
| Protection Features | Short Circuit, Under Voltage |
| Applications | Motor Drives, Inverters |
| Manufacturer | Mitsubishi Electric |
For more detailed information, please refer to the Mitsubishi Electric PS21963-4A datasheet.
