XP Power JCK3048D12 DC/DC Converter
XP Power JCK3048D12 Isolated DC/DC Converter
The XP Power JCK3048D12 is a high-performance isolated DC/DC converter designed to deliver reliable and efficient power in industrial and commercial applications. With its dual-output configuration, wide input voltage range, and advanced protection features, it ensures stable and safe operation in demanding environments.
Key Specifications
| Specification | Value |
|---|---|
| Input Voltage Range | 36V to 75V DC |
| Output Voltage 1 | +12V DC |
| Output Voltage 2 | -12V DC |
| Output Current per Channel | 1.25A |
| Output Power | 30W |
| Efficiency | Up to 90% |
| Isolation Voltage | 1.6kV |
| Operating Temperature | -40°C to +75°C |
| Mounting Type | Through Hole |
| Dimensions (L x W x H) | 50.8mm x 25.4mm x 10.16mm |
| Protection Features | OVP, OCP, SCP, UVLO |
| Control Features | Remote On/Off |
| Package Type | 6-DIP Module |
For more detailed information, please refer to the XP Power JCK3048D12 datasheet.
