GD300HFY120C2S IGBT Module
The GD300HFY120C2S is a high-power IGBT module designed to deliver reliable performance in demanding industrial and commercial power electronics. With a block voltage rating of 1,200 V and continuous collector current of 300 A (up to 600 A in pulsed operation), this module is well suited for heavy-duty applications. Engineered with trench IGBT technology, a DBC (Direct Bonded Copper) baseplate and low inductance package, it combines efficiency and ruggedness in one design.
Reliability is built-in: the module supports short-circuit capability (10 µs), has a maximum junction temperature up to 175 °C, and maintains stable operation from −40 °C to +150 °C. Its isolated copper baseplate and fast, soft reverse recovery diode help reduce losses during switching transitions, contributing to higher system efficiency and lower thermal stress.
This module finds ideal use in industrial inverters, UPS systems, motor drives, servo amplifiers, and AC or DC power conversion systems. Its half-bridge configuration and robust thermal and current handling make it suitable for both continuous and pulsed load conditions in commercial settings. Systems needing durable, efficient, and high-power switching components will benefit from the GD300HFY120C2S.
Key Specs
| Specification | Value / Description |
|---|---|
| Module Type | IGBT Module, Half Bridge |
| Manufacturer | STARPOWER Semiconductor |
| Block Voltage (Collector-Emitter) | 1,200 V |
| Continuous Collector Current (Tc = 25 °C) | 300 A |
| Pulsed Collector Current (tp = 1 ms) | 600 A |
| Gate-Emitter Voltage | ±20 V |
| Maximum Junction Temperature (Tj max) | 175 °C |
| Operating Temperature Range | −40 °C to +150 °C |
| Storage Temperature Range | −40 °C to +125 °C |
| Power Dissipation | ≈ 2.94 kW at rated junction/reference conditions |
| Saturation Voltage VCE(sat) (typ @ 300 A, 25 °C) | Approx. 1.70-2.10 V |
| Isolation / Baseplate | Isolated copper baseplate using DBC technology |
| Short-Circuit Capability | 10 µs short circuit rating |
| Applications | Inverters, UPS, Motor Drives, Servo Amplifiers, Industrial Power Systems |
