Semikron SKM200GAH123DKL 1200V 200A IGBT Module

SKM200GAH123DKL 1200 V 200 A IGBT Module – Semikron SEMITRANS M Chopper Module

The SKM200GAH123DKL is a rugged 1200 V, 200 A N-channel IGBT module from Semikron, designed for high-efficiency DC chopper and inverter systems. It provides ultra-low conduction loss and high short-circuit capability with fast free-wheeling diodes integrated inside the module. Its insulated copper baseplate using direct-bonded copper (DBC) ensures excellent heat dissipation and electrical isolation during operation.

This IGBT module has a typical saturation voltage (V\_CE(sat)\) of approximately 1.8 V at 25 ° C and 200 A collector current. It supports maximum junction temperatures up to 150 ° C, enabling stable performance under thermal stress.

The module features short internal connections to reduce stray inductance and fast switching speeds. It is optimized for use in industrial and automation systems including motor drives, servo control, welding inverters, and power supplies.

Key Specs Voltage Rating: 1200 V DC Current Rating: 200 A Continuous @ 25 °C (chopper mode) Technology: N-Channel IGBT with fast free-wheeling diode Package: SEMITRANS M Chopper Module with insulated copper DBC baseplate V\_CE(sat)\: ~1.8 V typ @ 200 A Rise Time: ~65 ns typ Operating Junction Temp: up to 150 °C Switching: Low inductance, fast-switching internal layout Applications: Motor Drives, AC/DC Choppers, Servo Systems, Welding Inverters, Power Supplies Brand: Semikron International (Semikron) Compliance: RoHS Compliant
