Mitsubishi PSS20S51F6 600V 20A IGBT Module
Regular price
Rs.0.00
PSS20S51F6 – High-Efficiency Intelligent Power Module for Compact Motor Drives
The Mitsubishi Electric PSS20S51F6 is a cutting-edge Intelligent Power Module (IPM) that delivers exceptional performance and reliability in low-power motor control applications. Designed using Mitsubishi’s advanced CSTBT technology, this module integrates a 3-phase DC/AC inverter with built-in gate drivers, protection circuits, and temperature monitoring, all within a compact and insulated transfer-molded package. With a voltage rating of 600V and a current rating of 20A, it is ideal for driving small motors in appliances such as air conditioners, washing machines, refrigerators, dishwashers, fans, and pumps. Its robust design ensures efficient power conversion, while its comprehensive protection features safeguard both the module and the connected systems.
The PSS20S51F6 stands out for its high efficiency, achieved through the use of CSTBT technology, which minimizes conduction losses and enhances overall system efficiency. The module's compact integration combines multiple components into a single unit, reducing board space requirements and simplifying design. Its enhanced durability ensures long-term reliability, even under demanding operating conditions. Additionally, the module is equipped with short-circuit (SC), under-voltage (UV), and over-temperature (OT) protection, along with fault signaling capabilities, providing comprehensive protection for both the module and the connected systems. The integrated temperature monitoring feature outputs an analog signal corresponding to the low-voltage integrated circuit (LVIC) temperature, facilitating system diagnostics and thermal management.
This module is designed for applications requiring robust performance and reliability, making it suitable for industrial and commercial use. Its comprehensive protection features, combined with its high efficiency and compact design, make it an excellent choice for engineers developing cost-sensitive, high-efficiency applications where board space and design time are at a premium. For more detailed information, please refer to the Mitsubishi Electric PSS20S51F6 Datasheet.
Key Specifications
| Feature | Specification |
|---|---|
| Voltage Rating (V_CES) | 600 V |
| Current Rating (±I_C) | 20 A |
| Isolation Voltage | 2500 Vrms |
| Operating Junction Temp (T_j) | 150°C |
| Package Type | Mini DIPIPM™ |
| Control Side Interface | 3V/5V Line, Schmitt Trigger |
| Protection Features | SC, UV, OT, Fault Signaling |
| Temperature Output | Analog Signal |
| UL Recognition | UL1557 File E80276 |
