GH-1C-12L 12V 10A Relay

GH-1C-12L Superminiature PCB Relay – 1C Contact, 10–15A Switching

The GH-1C-12L relay is a compact, high-power electromagnetic device designed for PCB mounting in consumer electronics, appliances, and remote-control systems. Featuring a 12 V DC coil with low power consumption, this GH-1C-12L relay delivers reliable performance within its small form factor of roughly 19.0 × 15.6 × 15.3 mm.

This superminiature relay supports 1 pole, 1 throw (1C) contact arrangements with switch ratings ranging from 5 A to 15 A at 125 VAC/28 VDC, and up to 6 A at 277 VAC, ideal for moderate load switching. It offers a contact resistance of 50 mΩ max, dielectric strength up to 1500 VAC between contacts and coils, and high durability with a mechanical life rating of 10 million operations and electrical life around 10,000 cycles.

Designed for modern electronics assembly, the GH-1C-12L relay is RoHS-compliant and built for mounting directly onto PCBs. Its low coil power consumption and robust switching make it ideal for automation, instrumentation, communication devices, and household appliances.

Key Specs Model: GH-1C-12L relay Coil Voltage: 12 V DC Contact Arrangement: 1C (1-pole changeover) Contact Rating: 5A–15A @ 125 VAC/28 VDC; 6A @ 277 VAC Contact Resistance: ≤ 50 mΩ Insulation Voltage: Up to 750 VAC (contacts), 1500 VAC (coil to contacts) Mechanical Life: 10 million operations Electrical Life: 10,000 switching cycles Dimensions: ~19.0 × 15.6 × 15.3 mm (PCB mount) Features: Superminiature size, low coil power, RoHS-compliant
