Fuji Electric 6MBI25GS 600V 25A IGBT Module
Guarantee Safe Checkout
Fuji Electric 6MBI25GS 600V 25A IGBT Module
6MBI25GS — 6 in 1 IGBT Module
The 6MBI25GS is a six-pack IGBT module designed for medium-power inverter and motor-drive systems. It offers a collector-emitter blocking voltage of 600 V and a continuous collector current rating of 25 A. The module features low on-state voltage, reduced switching losses, and minimized internal stray inductance, making it suitable for UPS units, servo drives, welding equipment, and industrial motor controllers.
This IGBT module provides consistent electrical characteristics, including a square RBSOA and optimized freewheel diodes, allowing stable operation under transient and dynamic load conditions. Its thermal and electrical performance support operation across a wide temperature range, which ensures long-term service in both industrial and commercial environments.
The 6MBI25GS is commonly applied in inverter motor drives, AC/DC servo amplifiers, UPS systems, and welding machines. It is supplied in a compact single-inline package that simplifies integration into converters and industrial control equipment. For complete design data including electrical limits, thermal resistance, and mechanical drawings, refer to the official datasheet.
Key Specs
| Parameter | Value |
|---|---|
| Part number | 6MBI25GS-060 |
| Manufacturer | Fuji Electric |
| Collector-Emitter voltage (VCES) | 600 V |
| Continuous collector current (IC, Tc = 25°C) | 25 A |
| Power dissipation (Pc, at Tc) | 180 W |
| Operating junction temperature | –40 to +150 °C |
| Gate-Emitter voltage (VGE, max) | ±20 V |
| Isolation voltage (Vis) | AC 2500 V, 1 min |
| Module type | 6-in-1 IGBT, single in-line package |
| Typical applications | Inverter drives, servo amplifiers, UPS, welding machines |
For more detailed information, please refer to the Fuji Electric datasheet.
