680uF 550V Aluminum Electrolytic Capacitor

680uF 550V High Voltage Aluminum Electrolytic Capacitor

The 680uF 550V aluminum electrolytic capacitor is designed for high-voltage power applications where stable performance, low equivalent series resistance (ESR), and high ripple current handling are required. With a capacitance of 680 microfarads and a voltage rating of 550 volts, this capacitor supports energy storage, DC bus filtering, and voltage smoothing in systems such as industrial power supplies, inverters, and motor drives.

It features an aluminum electrolytic construction, offering thermal stability and long operational life. The capacitor is typically rated for operation up to +105°C and is available in snap-in or screw-terminal configurations for compatibility with various mounting requirements. Its low ESR and high ripple current capacity make it suitable for use in high-frequency and continuous-duty applications, including UPS systems, welding machines, and EV charging circuits.

The 680uF 550V capacitor meets RoHS standards and is built for consistent electrical performance in high-power environments.

Key Specs

Capacitance: 680uF Voltage Rating: 550V DC Technology: Aluminum Electrolytic Package: Snap-in or Screw Terminal ESR: Low (typ. 0.21–0.51Ω) Ripple Current: Up to 3.35A Temperature Range: -40°C to +105°C Applications: DC Link, Inverters, Power Supplies, UPS, Motor Drives Brand: Multiple (KEMET, Vishay, Nichicon) Compliance: RoHS & Pb-Free
