820uF 550V Electrolytic Capacitor
Regular price
Rs.680.00
Sale price
Rs.700.00
820uF 550V Electrolytic Capacitor
The 820 µF 550 V Snap‑In Electrolytic Capacitor is designed for high‑voltage power applications, including industrial inverters, DC link circuits, energy storage systems, and power supplies. It provides stable energy buffering and voltage filtering under demanding conditions. With a capacitance tolerance of ±20 % and low equivalent series resistance (ESR), this capacitor maintains reliable performance in environments that require consistent voltage handling.
Constructed with a robust aluminum body, the capacitor operates across a wide temperature range from −40 °C to +85 °C and is rated for long-term use. Its radial snap‑in package ensures secure mounting and effective thermal management in compact assemblies. The low ESR and high ripple current handling (~3.7 A at 120 Hz) support efficient power conversion and reduce heat generation during operation.
This capacitor meets RoHS compliance standards and is suitable for applications in industrial control systems, high-voltage converters, power factor correction units, and renewable energy systems. Its long operating life of 3,000 hours at 85 °C provides reliable performance over extended periods.
Key Specs
| Specification | Value |
|---|---|
| Capacitance | 820 µF |
| Voltage Rating | 550 V DC |
| Tolerance | ±20 % |
| Ripple Current | ~3.7 A @ 120 Hz |
| Equivalent Series Resistance (ESR) | ~150 mΩ |
| Load Life | 3,000 hours @ 85 °C |
| Operating Temperature | −40 °C to +105 °C |
| Dimensions | ~45 mm diameter × 70 mm height |
| Package | Snap‑in radial |
| Compliance | RoHS Compliant |
| Applications | Industrial inverters, DC link, power supplies, high‑voltage filtering |
